Punches & Spring Punches |
PUNCH & SPRING PUNCH
Tube Punch Type : AE |
![](/UploadFile/201181113589210.jpg) |
Edge Dia
øA |
Ext. Dia
øF |
Height
H |
1.5
2
2.5
3
4
5
6
7
8 |
2.5
3
3.5
4
4.5
6
7
8
9 |
8 (9.5)
8 (9.5)
8 (9.5)
8 (9.5)
8 (9.5)
8 (9.5)
8 (9.5)
8 (9.5)
8 (9.5) |
Spring Punch Type: AD |
![](/UploadFile/2011811135832230.jpg) |
Edge Dia
øA |
Ext. Dia
øF |
Height
H |
2
2.5
3
3.5
4
4.5
5
5.5
6
7
8 |
5
5
5
5.5
6
6.5
7
7.5
8
9
10 |
23.80 mm
23.80 mm
23.80 mm
23.80 mm
23.80 mm
23.80 mm
23.80 mm
23.80 mm
23.80 mm
23.80 mm
23.80 mm |
Aircraft Punch Type: AF |
![](/UploadFile/2011811135847554.jpg) |
L |
12 – 36 mm |
C |
8 - 29 mm |
H |
7.5 – 12 mm |
A |
4 - 7 mm |
One Side Punch Type: ZE |
![](/UploadFile/2011811135921630.jpg) |
Dia ø |
0.5 – 10.0 mm |
|
|
|
Type: YE |
![](/UploadFile/2011811135939595.jpg) |
Dia ø |
3.0 – 8.0 mm | |
|
|
